20030120 3-3-9 T7401EL
CRT CBA
RCA JACK(WHITE) AV1-15-4 JXRL010RP014
JK801 EARPHONE JACK MSJ-035-12APC or JYSL030LY001
EARPHONE JACK HTJ-035-1ZEBTZ or JYSL030GE001
EARPHONE JACK HSJ1403-01-010 JYSL030HD002
PS601# THERMISTOR ZPB45BL7R0A QNZZ45BL7R0A
RS201 REMOCON RESEVER Z12-RS01 or USESJRSUNT04
REMOTE RECEIVER PIC-37042LU USESJRSKK033
SA601# SURGE ABSORBER JVR-07N471K or NVQZVR07N471
# SURGE ABSORBER CNR-10D471K or NVQZR10D471K
# SURGE ABSORBER CNR-07D471K or NVQZR07D471K
# SURGE ABSORBER PVR-07D471KB NVQZ07D471KB
SF001 SAW FILTER SAFGM45M7VHHzC0B03 FBB456PMR008
SG001# GAP. FNR-G3.10D FAZ000LD6005
T571# FLYBACK TRANSFORMER JF0501-3201A LTF00CPXB040
T572 H0RIZONTAL DRIVE TRANS LP2-005 LTH00CPA5005
T601# SWITCHING TRANS 02712 LTT00CPKT101
TB3 HEAD SHIELD(DC) T5400UA 0EM301721
TB7 LED HOLDER T5400UA 0EM407679
TB9 19VPOW HEAT SINK PHB ASSEMBLYT7400UA 0EM407685
TB21 BUSH, LED(F) H3700UD 0VM409508
TB26 13V H/V HEAT SINK PGZ T5400UA 0EM301720
TL2 SCREW, B-TIGHT M3X8 BIND HEAD+ or GBMB3080
SCREW, B-TIGHT M3X8 BIND HEAD+ GBMB3080
TP201 PCB JUMPER D0.6-P5.0 JW5.0T
TP301 PCB JUMPER D0.6-P17.5 JW17.5T
TP302 PCB JUMPER D0.6-P5.0 JW5.0T
TP401 PCB JUMPER D0.6-P20.0 JW20.0T
TP402 PCB JUMPER D0.6-P17.5 JW17.5T
TU001# TUNER B8135AP or UTUNNTUSP023
# TUNER ENV56DC9G3 UTUNNTUMS010
VR601# CARBON P.O.T. 10k Ω B or VRCB103KA011
# CARBON P.O.T. 10k Ω B VRCB103HH014
W601# AC CORD PB8K9F9110A-057 or WAC0172LW008
# AC CORD WAC0172LTE01 or WAC0172LTE01
# AC CORD WAC0172AS006 or WAC0172AS006
# AC CORD LA-2366 or WAC0172LW006
# AC CORD A0A0280-007 WAC0172LTE04
X201 X'TAL 32.768kHz(20PPM) or FXC323LJNY01
X'TAL 32.768kHz(20PPM) or FXC323LCT001
X'TAL 32.768kHz(20PPM) or FXC323LDS002
X'TAL 32.768kHz(20PPM) FXC323LQUA01
X202 X'TAL HC-49/U 10.6MHz or FXD106LLN001
X'TAL AT49-10.6 or FXD106LDS002
X'TAL :10.6MHz S8562 FXD106LCT001
X301 X'TAL 3.579545 MHz or FXD355LLN003
X'TAL 3.579545MHz(30PPM) FXD355LCHE01
X401 X'TAL 3.579545MHz(20PPM) or FXC355LJNY01
X'TAL 3.579545MHz(20PPM) or FXC355LLN003
X'TAL 3.579545MHz(20PPM) or FXC355LDS001
X'TAL 3.579545MHz or FXC355LLN001
X'TAL 3.579545MHz(20PPM) FXC355LCHE01
Ref. No. Description Part No.
CRT CBA
Consists of the following
------------
CAPACITORS
C501 CERAMIC CAP. B K 1000pF/2KV or CCD3DKP0B102
CERAMIC CAP. B K 1000pF/2KV or CA3D102MR030
CERAMIC CAP. B K 1000pF/2KV CCD3DKD0B102
Ref. No. Description Part No.
C502 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL010
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C511 CHIP CERAMIC CAP. B K 470pF/50V CHD1JKB0B471
C521 CHIP CERAMIC CAP. B K 470pF/50V CHD1JKB0B471
C531 CHIP CERAMIC CAP. B K 470pF/50V CHD1JKB0B471
CONNECTORS
CN505 PIN CONNECTOR 005P-5100 or JTEA001TG001
CONNECTOR PIN, 1P LV or 1700576
CONNECTOR PIN, 1P RT-01N-2.3A 1730688
TRANSISTORS
Q511 TRANSISTOR 2SC2482 TPE6 or QQSZ02SC2482
TRANSISTOR 2SC3468(E)-AE or QQSE02SC3468
TRANSISTOR 2SC3468(D)-AE or QQSD02SC3468
TRANSISTOR KTC3207 NQSZ0KTC3207
Q521 TRANSISTOR 2SC2482 TPE6 or QQSZ02SC2482
TRANSISTOR 2SC3468(E)-AE or QQSE02SC3468
TRANSISTOR 2SC3468(D)-AE or QQSD02SC3468
TRANSISTOR KTC3207 NQSZ0KTC3207
Q531 TRANSISTOR 2SC2482 TPE6 or QQSZ02SC2482
TRANSISTOR 2SC3468(E)-AE or QQSE02SC3468
TRANSISTOR 2SC3468(D)-AE or QQSD02SC3468
TRANSISTOR KTC3207 NQSZ0KTC3207
RESISTORS
R510# METAL OXIDE FILM RES. 1W J 15k Ω or RN01153ZU001
# METAL OXIDE FILM RES. 1W J 15k Ω RN01153DP003
R511 CHIP RES.(1608) 1/10W J 15 Ω RRXAJB5Z0150
R512 CARBON RES. 1/4W J 56k Ω or RCX4JATZ0563
CARBON RES. 1/6W J 56k Ω RCX6JATZ0563
R513 CARBON RES. 1/4W J 56k Ω or RCX4JATZ0563
CARBON RES. 1/6W J 56k Ω RCX6JATZ0563
R515 CARBON RES. 1/4W J 470 Ω or RCX4JATZ0471
CARBON RES. 1/6W J 470 Ω RCX6JATZ0471
R516 CARBON RES. 1/4W J 1.5k Ω or RCX4JATZ0152
CARBON RES. 1/6W J 1.5k Ω RCX6JATZ0152
R517 CARBON RES. 1/4W J 1.5k Ω or RCX4JATZ0152
CARBON RES. 1/6W J 1.5k Ω RCX6JATZ0152
R520# METAL OXIDE FILM RES. 1W J 15k Ω or RN01153ZU001
# METAL OXIDE FILM RES. 1W J 15k Ω RN01153DP003
R521 CHIP RES.(1608) 1/10W J 15 Ω RRXAJB5Z0150
R522 CARBON RES. 1/4W J 56k Ω or RCX4JATZ0563
CARBON RES. 1/6W J 56k Ω RCX6JATZ0563
R523 CARBON RES. 1/4W J 56k Ω or RCX4JATZ0563
CARBON RES. 1/6W J 56k Ω RCX6JATZ0563
R525 CARBON RES. 1/4W J 470 Ω or RCX4JATZ0471
CARBON RES. 1/6W J 470 Ω RCX6JATZ0471
R526 CARBON RES. 1/4W J 1.5k Ω or RCX4JATZ0152
CARBON RES. 1/6W J 1.5k Ω RCX6JATZ0152
R527 CARBON RES. 1/4W J 1.5k Ω or RCX4JATZ0152
CARBON RES. 1/6W J 1.5k Ω RCX6JATZ0152
R530# METAL OXIDE FILM RES. 1W J 15k Ω or RN01153ZU001
# METAL OXIDE FILM RES. 1W J 15k Ω RN01153DP003
R531 CHIP RES.(1608) 1/10W J 15 Ω RRXAJB5Z0150
R532 CARBON RES. 1/4W J 56k Ω or RCX4JATZ0563
CARBON RES. 1/6W J 56k Ω RCX6JATZ0563
R533 CARBON RES. 1/4W J 56k Ω or RCX4JATZ0563
CARBON RES. 1/6W J 56k Ω RCX6JATZ0563
R535 CARBON RES. 1/4W J 470 Ω or RCX4JATZ0471
CARBON RES. 1/6W J 470 Ω RCX6JATZ0471
R536 CARBON RES. 1/4W J 1.5k Ω or RCX4JATZ0152
Ref. No. Description Part No.
