Symphonic 6319CD/EWC1903 - Page 91

20030120 3-3-10 T7401EL
SENSOR CBA
CARBON RES. 1/6W J 1.5k Ω RCX6JATZ0152
R537 CARBON RES. 1/4W J 1.5k Ω or RCX4JATZ0152
CARBON RES. 1/6W J 1.5k Ω RCX6JATZ0152
MISCELLANEOUS
CL501A LEAD WIRE 3P/430MM WX1T7400-001
CL502A LEAD WIRE 4P/450MM WX1T7400-002
JK501# CRT SOCKET ISMS02S JSCC220PK003
Ref. No. Description Part No.
SENSOR CBA
Consists of the following
0ESA04524
TRANSISTORS
Q201 PHOTO TRANSISTOR MID-32A22 NPWZM1D32A22
Q202 PHOTO TRANSISTOR MID-32A22 NPWZM1D32A22
Ref. No. Description Part No.
