20030120 3-4-1 T7401DPL
DECK PARTS LIST
Ref.
No
Description Part No.
B2 CYLINDER ASSEMBLY MK12 NTSC 2HD N1628CYL
B3 LOADING MOTOR ASSEMBLY MK11 TVCR 0VSA13465
B8 PULLEY ASSEMBLY MK12 0VSA13500
B9 MOVING GUIDE S PREPARATION MK12 0VSA13560
B10 MOVING GUIDE T PREPARATION MK12 0VSA13562
B11 LOADING ARM(TU) ASSEMBLY MK12 0VSA13300
B12 LOADING ARM(SP) ASSEMBLY MK12 0VSA13299
B31 AC HEAD ASSEMBLY MK12(TVCR) 0VSA13517
B35 TAPE GUIDE ARM ASSEMBLY MK12 0VSA13277
B37 CAPSTAN MOTOR 288/VCCM012 N9670CML
B52 CAP BELT MK10 0VM411138
B73 FE HEAD ASSEMBLY MK11 or N9742FEL
FE HEAD ASSEMBLY MK11 or N9743FEL
FE HEAD(MK11) MH-131SF11 or DHVEC01Z0005
FE HEAD(MK11) VTR-1X2ERS11-148 or DHVEC01TE004
FE HEAD(MK12) VTR-1X2ERS11-155 or DHVEC01TE005
FE HEAD(MK12) HVFHP0047A DHVEC01AL007
B74 PRISM MK10 0VM202870
B121 WORM MK12 0VM414091
B126 PULLEY MK12 0VM414330
B133 IDLER GEAR MK12 0VM305738
B134 IDLER ARM MK12 0VM305739
B148 TG CAP MK11 0VM412972
B300 C DRIVE LEVER(TU) MK12 0VM203773
B303 F DOOR OPENER MK12 0VM203751
B313 C DRIVE SPRING MK12 0VM414145
B347 GUIDE HOLDER A MK10 0VM304920
B354 SLIDER(TU) MK12 0VM101172
B355 SLIDER(SP) MK12 0VM101182
B359 CLEANER LEVER MK10 0VM304413
B360 CLEANER ROLLER MK9 0VM410032C
B361 CL POST MK10 0VM411114
B410 PINCH ARM ASSEMBLY(1) MK12 or 0VSA13285
PINCH ARM ASSEMBLY(3) MK12 or 0VSA13288
PINCH ARM(A) ASSEMBLY(4) MK12 0VSA13572
B411 PINCH SPRING MK12 0VM414644
B414 M BRAKE(SP) ASSEMBLY MK12 0VSA13282
B416 M BRAKE(TU) ASSEMBLY MK12 0VSA13283
B417 TENSION SPG(360261) MK12 0VM414221
B425 LOCK LEVER SPRING MK10 0VM411110
B426 KICK PULLEY MK10 0VM411095
B482 CASSETTE PLATE MK12 0VM203749
B483 LOCK LEVER MK12 0VM414095
B487 BAND BRAKE(SP) MK12 0VM305723
B488 MODE LEVER MK12 0VM101173
B491 CAM GEAR(A) MK12 0VM101174
B492 MODE GEAR MK12 0VM203769
B494 C DOOR OPENER MK12 0VM305719
B499 T LEVER HOLDER MK12 0VM305729
B501 WORM HOLDER MK12 0VM203767
B502 CAM GEAR(B) MK12 0VM305721
B507 REEL WASHER MK9 5*2.1*0.5 0VM410058
B508 S BRAKE SPRING MK10 0VM411121
B514 SCREW RACK MK10 0VM411535
B516 REEL WASHER MK9 5*2.1*0.5 0VM410058
B520 TU BRAKE SPRING MK12 0VM414285
B521 REV BRAKE SPRING MK12 0VM414222
B522 TG POST ASSEMBLY MK11 0VSA12080
B525 LDG BELT MK11 0VM412804
B529 CLEANER ASSEMBLY MK10 0VSA11161
B553 REV SPRING MK11 0VM412555
B555 RACK ASSEMBLY MK12 0VSA13289
B557 MOTOR PULLEY U5 0VM403205A
B558 LOADING MOTOR MDB2B82 or MMDZB10SJ001
LOADING MOTOR MDB2B80 MMDZB12SJ008
B559 CLUTCH ASSEMBLY MK12 0VSA13284
B560 KICK SPRING MK10 0VM411475A
B561 F DOOR SPRING MK10 0VM411430
B562 C DRIVE LEVER(SP) MK12 0VM203772
B563 SLIDER SHAFT MK12 0VM305762
B564 M GEAR MK12 0VM305735
B565 SENSOR GEAR MK12 0VM305736
B567 PINCH ARM(B) MK12 0VM305718
B568 BT ARM MK12 0VM305728
B569 CAM HOLDER(F) MK12 0VM305722
B570 CAM RACK SPRING(HI) MK11 0VM412923
B571 P.S.W CUT 1.6X4.0X0.5T 0VM408485A
B573 REEL(SP)(D2) MK12 0VM203755
B574 REEL(TU)(D2) MK12 0VM203756
B587 TENSION LEVER ASSEMBLY MK12 0VSA13279
B589 TENSION LEVER MK12 0VM305727
B590 BRAKE ARM(TU) MK12 0VM203752
B591 BAND BRAKE(TU) MK12 0VM305724
B592 TG POST MK11 0VM412550
B594 M BRAKE S MK12 0VM203753
L1051 SCREW, B-TIGHT M2.6X6 PAN HEAD+ GPMB9060
L1053 SCREW, S-TIGHT M2.6X8 WASHER HEAD+ GCMS9080
L1151 SCREW, SEMS M3X4 PAN HEAD + CPM33040
L1191 SCREW, S-TIGHT M2.6X8 WASHER HEAD+ GCMS9080
L1321 SCREW, S-TIGHT M3X6 BIND HEAD+ GBMS3060
L1406 AC HEAD SCREW MK9 0VM410964
L1450 SCREW, SEMS M2.6X5 PAN HEAD+ CPM39050
L1466 SCREW, S-TIGHT M2.6X6 BIND HEAD+ GBMS9060
L1467 SCREW, S-TIGHT M2.6X5 WASHER HEAD+ GCMS9050
Ref.
No
Description Part No.
