Technical Manual 8
Plumbing Instructions
This equipment is to be installed to comply with the applicable federal, state or local plumb-
ing codes.
Connect the 3/8” compression tting of the provided stainless steel braided hose to the
connection from the ltered, cold water line.
The ¾” inside diameter clear vinyl ribbed hose connects the outlet tting of the drain box to
the drain (located on the right hand, bottom, rear corner). Run this hose to the oor drain or
oor sink.
Fittings on the hoses are 3/8” compression type ttings, thread sealant or Teon tape is not
necessary. Make connections snug, but do not over tighten.
Turn water ON and check for leaks.
NOTE: The Synesso™ requires a minimum of 35 PSI of line pressure to have the steam
tank auto-lling system function properly.
Electrical Instructions
After you make sure your receptacle and circuit are rated for the proper voltage and
amperage (see specications chart on page 9) for your model, install a matching plug on
the power cord provided with the Synesso™ machine.
North American Conguration Outside of North America
Green Ground Green Ground
White 110 V White 220 V
Black 110 V Black Neutral
Make sure that the On/Off electronics switch (red rocker) and the heating element breaker
on the Synesso™ are in the OFF (0) position, then plug the power cord into the receptacle.
IMPORTANT - If the voltage on the receptacle used is less than 210 Volts, it may be nec-
essary to install an in-line Buck-Boost transformer to increase this voltage.
• 1 and 2 Group 220 Volt Machines require a 1.0 KVA transformer
• 3 Group 220 Volt Machines require a 1.5 KVA transformer.
INSTALLATION
