2 QSG ti-Series Laser Ver 2.5
ti-Series Laser Quick Start Guide
1.1 Locate the wire harness in
side one of the foam end caps.
1.3 Drape the wire harness across
the top of the laser housing when
carrying.
2.0 Don’t forget the laser’s kit
at the bottom of your box!
1. Unseat the wiring by sliding the harness out of the notch, then down and out of the foam as shown.
2. Locate the shipping components for the at the bottom of the box under the laser.
1.2 Push the wire harness through the
notch in the foam.
Laser Unpacking (Continued):
Note: IF using the Flyer 3D marking head with your laser, review the following sections in this guide, also
see the Mounting & Flyer 3D Quick Start Guide and reference the Flyer 3D WMPv7 QSG located on
our website. Otherwise, see the note below.
Note: IF using the FH Flyer marking head with your laser, go to the Mounting & FH Flyer Quick Start Guide
and reference the FH Flyer & WMPv6 QSG located on our website.
Note: If water and/or air cooling is desired, please see the Cooling Quick Start Guide and Cooling 101
located on our website in addition to this guide.
