Synrad Firestar TI Series Quick Start Guide

3 QSG ti-Series Laser Ver 2.5
ti-Series Laser Quick Start Guide
(H2O-Cooled ti80 Shown)
AVOID EXPOSURE
Invisible laser radiation
is emitted from
this aperture.
Mounting feet and/or rails are optional. See the laser & marking head’s Operation Manual,
Mounting Quick Start Guide, and drawings on our website: www.synrad.com for further infor-
mation.
Consult the factory for further mounting angle guidance outside >75% from the horizontal. When mounting
the laser to a baseplate, use only one metric or SAE fastener per mounting tab on the baseplate. Do not use
any type of jackscrew arrangement as this will twist the baseplate and may distort the tube.
SYNRAD does not recommend mounting lasers in a vertical, (head and/or tail down)
position. Please contact the factory for limitations as a vertical orientation increases the
risk of damage to the lasers optics.
Remove the
aperture seal.
Readying your Laser for use:
SYNRAD oers the UC-2000 controller for those who want simplicity. If you are using the UC-2000 to control
your laser, see the UC-2000 Quick Start Guide located on our website. Do not forget to perform the initial
startup procedure located at the end of this guide.
Caution
Possible equip-
ment damage
Failure to
remove can
damage the
laser!
3. Before mounting the laser, ensure the aperture seal is removed.
Note: SYNRAD oers the UC-2000 controller for those who want simplicity. If controlling your laser by our
UC-2000, also reference the associated quick start guide.
