4 QSG ti-Series Laser Ver 2.5
ti-Series Laser Quick Start Guide
Mounting (with out a SYNRAD Marking Head):
6. Choose your mounting type.
A. Mounting from below (UNC fastners only).
B. Mounting from above (ISO/UNC fastners).
4. The Mounting Hardware ( ) also has your particular laser model’s hardware per your
models features.
5. Tighten all three capscrews to a torque of 6 ft lb (8 Nm) maximum.
Note: IF not using a SYNRAD marking head OR mounting kit with your laser, see the following appli-
cable sections in this guide.
