How to Operate 60 Series Controller– 106
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Conditions:
Executing M00 under "Busy" statue.
Single block function is triggered under "Busy" state.
Note:
Under "B-Stop" state, spindle will keep rotating.
5.2 Machine Preparation
5.2.1 Manual Function
SYNTEC controller provides 4 functions used to control axis movement including JOG, INC JOG, MPG and Rapid
JOG
JOG
Function:
Control the axis movement toward the selected direction
Can control more than one axis at the same time
Condition:
System is on "Ready" state
JOG mode is selected
Operation:
Press axis direction key (X+,X-,Y+,Y-,Z+…)
Hold the axis direction key to keep the axis moving uninterrupted
JOG speed can be adjusted by G01%
Rapid JOG
Function:
Control axis movement toward the selected direction with G00 speed
Can control more than one axis at the same time
Condition:
System is on "Ready" state
JOG mode is selected
Operation:
Press rapid key "〜 ", then press axis direction key (X+,X-,Y+,Y-,Z+…) at the same time ,machine
will move with G00- rapid speed
Hold the axis direction key to keep the axis moving uninterrupted
Rapid JOG speed can be adjusted by G00%
Note:
Rapid JOG is usually much faster than JOG, so when operating, please confirm the axis position to
ensure human and machine safety.
INC JOG (incremental JOG)
Function:
Control axis movement toward the selected direction with fixed distance(incremental distance)
