9. TROUBLE SHOOTING
9.1 Crease motor error/Jamming the blade
9.1.1 Feed too many papers in one pass.
9.1.2 Set the blade too low.
9.1.3 Run the thicker paper than the blade are set for
Solution:
1. Carefully use the scroll buttons to move the rollers and pull the
paper out, find the every reason and solve it accordingly.
2. If above doesn’t work, please uninstall the unit, and test the machine from the
beginning.
9.2 Paper jam
9.2.1 The paper is too thin ( under spec, the paper will crumple ).
9.2.2 There is some waste present in the pass path of the machine.
9.2.4 There is too much ambient light shining on the IR sensor ( especially direct
sunlight or neon light which will send fake paper jam signal).
9.2.5 The lead edge of the paper is being damaged by the paper separator.
Solution:
Use the scroll buttons to control the roller manually to drive the
jammed paper out of mechanical system . do not pull hard on the paper, or you
may damage the in-feed rollers !
9.3 Feed failure
9.3.1 The feeding roller can not scratch the paper.
Solution: Put a weight on the feeding roller.
9.4 Bubbling in laminated stock
9.4.1 This occurs if you try to crease laminated paper. The curve of the crease will
not adhere to the film
solution: Make a shallower crease or use a better film.
9.5 Paper wrapped around the perforating wheels
9.5.1This occurs if the card is too thin/ has no body and will get hooked on the
perforating teeth and wrap around the disc.
solution: keep the paper within the spec..
