SYSFORM CP330B - Operational Adjustments; Creasing Skew Adjustment

19
Press or to choose "mm" or "inch" then press .
7. Adjustment
7.1 Creasing skew
7.1.1 Adjust the side lay on the table to get a proper feeding angle. Loosen the two
screws then adjust the angle of the side lay then tighten the two screws as shown
in the illustration.
