A - 3
Appendices
NA-series Programmable Terminal Hardware User’s Manual (V117)
A-1 Dimensions
A
A-1-1 NA Units
 NA Units
 Cable Connection Dimensions
NA5-12W
194.2
309
340
244
6
33.5
69.1
139.1
220
(Unit: mm)
0
41.6
42
41.2
10.9 10.4
25.8
55
24.8
47.3
55.7
3
17
44
71 73
32.6
39.6 42.1
37
36 69.3
(Unit: mm)
