MAINTENANCE AND SUPPLIES REPLACEMENT
4-18 Sysmex KX-21 Operator’s Manual -- Revised October 1998
• When removing the tray, take care not to loosen the probe fixing screw.
If analysis is made with the screw loosened, air can enter the system
and affect the data.
(5) Gently push down the rinse cup using both hands. Make sure the rinse cup is
removed completely from the sample probe.
Sample Probe
Rinse Cup
Figure 4-6-4: Pushing Down the Rinse Cup
CAUTION: • If the rinse cup is not completely removed from the sample probe, there
is a possibility that the sample probe may bend when the sample rotor
valve (SRV) is removed.
(6) Remove the SRV fixing screw.
SRV Fixing Screw
Loosen
Figure 4-6-5: Removing the SRV Fixing Screw
CAUTION
To Next Page
