MAINTENANCE AND SUPPLIES REPLACEMENT
Sysmex KX-21 Operator’s Manual -- Revised October 1998 4-27
(5) Clean the rinse cup using tap water.
Figure 4-7-5: Cleaning the Rinse Cup
(6) Make sure no contaminant remains on the rinse cup and wipe off water.
(7) Mount the rinse cup in the reverse order of removal. Route the thin tubes around the
rear of the rinse cup.
Rinse Cup
3
2
1
Figure 4-7-6: Mounting the Rinse Cup
(8) Gently push up the rinse cup to the top using both hands.
CAUTION: • Make sure the rinse cup is pushed all the way up with the sample
probe inserted in the hole. If the power is turned on with the rinse cup
staying lowered, "Rinse Motor Error" will occur, making it impossible to
continue the operation.
