CALIBRATION
6-4 Sysmex KX-21 Operator’s Manual -- Revised October 1998
2.2 Automatic Calibration Procedure
1. Selecting Automatic Calibration Parameter
(1) Using [ ] or [ ] key, move the cursor to select an automatic calibration parameter on
the Automatic Calibration Menu Screen:
[1: HGB]: Calibrates HGB alone.
[2: HGB/HCT]: Calibrates two parameters of HGB and HCT at the same time.
[3: HCT]: Calibrates HCT alone.
NOTE: • Each menu can be selected directly by entering a numeral from the
numeric keys.
(2) Press [ENTER] key.
The Automatic Calibration screen for the selected parameter appears.
Target
HGB
1
2
3
4
5
Data
HGB
Compensation
HGB
Current Cal.(%)100.0
New Cal.(%)
*
Auto Cal.
*
Press [SELECT] to Set.
Figure 6-2-3: HGB Automatic Calibration Screen
Target
HGB
HCT HCT HCT
1
2
3
4
5
Data
HGB
Compensation
HGB
Current Cal.(%)100.0 100.0
New Cal.(%)
*
Auto Cal.
*
Press [SELECT] to Set.
Figure 6-2-4: HGB/HCT Automatic Calibration Screen
