TROUBLESHOOTING
Sysmex KX-21 Operator’s Manual -- Revised October 1998 7-13
3.3 Motor Errors
Error Message Meaning of Message
"Rinse Motor Error"
ERR CODE:XXXXX.X.X
*
Help
*
Error on Rinse Cup
Turn OFF then ON the power.
If Rinse Cup is out of position,
Turn power OFF and correct manually.
3:Ana.Screen
The rinse cup is at lower position at start-up
(This happens only when the power is ON.)
Cause 1) Rinse cup drive motor malfunction
2) The power was turned ON with the rinse cup remaining lowered.
Action 1) Turn OFF the power, manually raise the rinse cup with both hands
to the original top position, then turn ON the power.
Analysis after error
occurrence
The power needs to be turned OFF then ON again.
NOTE: • Press [3] key to return to the Analysis screen. The status is not ready for
analysis, but the processing, etc. of stored data in Select Menu can be
performed.
