TROUBLESHOOTING
7-14 Sysmex KX-21 Operator’s Manual -- Revised October 1998
Error Message Meaning of Message
"Rinse Motor Error"
ERR CODE:XXXXX.X.X
*
Help
*
Error on Rinse Cup
Turn OFF then ON the power.
3:Ana.Screen
The rinse cup is not operating normally.
Cause 1) Rinse cup drive motor malfunction
2) Error of the rinse cup drive motor controller
Faulty operation of CPU due to sudden noise interference, etc.
Action 1) Turn OFF the power and check to see that tubing, etc. are not in
contact with the top or bottom of rinse cup.
2) Turn OFF the power and clean the rinse cup.
Refer to Chapter 4, Section 7.2: Clean Rinse Cup.
Analysis after error
occurrence
The power needs to be turned OFF then ON again.
NOTE: • Press [3] key to return to the Analysis screen. The status is not ready for
analysis, but the processing, etc. of stored data in Select Menu can be
performed.
