INSTALLATION
Sysmex KX-21 Operator’s Manual -- Revised October 1998 A-5
(4) Remove the pneumatic unit fixing screws (2 pcs). Keep these screws for future use.
Fixing Screws
Figure A-4-3: Removing the Screws
(5) Remove the rubber caps of the reagent connection nipples. Keep these rubber caps for
future use.
Rubber Caps
Figure A-4-4: Removing the Rubber Caps
