5.5 Using the optional USB connection
Unscrew and remove the dummy plug on the left-hand side of
the WAVE 224 monitor/thin client.
ð
The optional USB connection is now accessible.
When closing the USB connection, make sure it is
screwed tight, otherwise the IP65 protection level can
no longer be guaranteed.
Firmly screw the dummy plug into place on the left-hand side of
the WAVE 224 monitor/thin client.
ð
The optional USB connection is firmly screwed shut.
5.6 Setting up the WLAN (optional)
The WLAN antenna together with the WLAN USB stick are
located in the equipment rack adapter.
The WLAN USB stick may be connected only directly to a USB
interface with no interposed USB hub.
Opening dummy plugs
Closing dummy plugs
Operation
Setting up the WLAN (optional)
WAVE 224 monitor/thin client - Industrial monitor/thin client
