3.5 External connectors
3.5.1 Overview of external connections
The following illustration shows the connectors that are located on the
back of the WAVE 224 monitor/thin client.
Fig. 9: Overview of the interfaces on the back (depending on the configura-
tion)
3.5.2 Description of the external connections
Your device will not incorporate all of the following connectors (see
Ä
Chapter 3.3 “Technical data for the device” on page 13).
= 9-pole Sub-D socket for connecting serial devices
Fig. 10: Serial connection (RS
‑
232)
= 24-pole DVI socket for connecting to the basic computer
Fig. 11: DVI socket with pinout
= 19-pole HDMI socket for connecting to the basic computer
Fig. 12: HDMI socket with pinout
Serial connection (RS‑232)
DVI port
HDMI port
Product description
External connectors > Description of the external connections
WAVE 224 monitor/thin client - Industrial monitor/thin client
17
