6
7
1
2
3
5
4
Fig. 5: Type plate
No. Description
1 Product name
2 Serial number
3 Power supply and consumption, charge current
and battery capacity (only for devices with an inte-
grated battery)
4 CE mark
5 Manufacturer’s logo
6 QR code (S/N + product name)
7 Manufacturer’s address
3.3 Technical data for the device
System
Model WAVE 224
Variant Monitor
Housing material Stainless steel 1.4301
Surface glass-beaded, optionally sanded
IP protection factor IP65
Display
Type of display 24" IPS LCD display with LED backlight
Display area 531.36 x 298.89 mm
Native (maximum) resolution 1920 x 1080 (Full HD)
Page ratio 16:9
Colors 16.7 million
Brightness
300 cd/m
2
Contrast 3000:1
Response time 25 ms
Product description
Technical data for the device
WAVE 224 monitor/thin client - Industrial monitor/thin client
13
