P/N: 60400601
REV: 02/04
6
Power Requirements: 115VAC, 60 Hz, 12A
Environment: 41°F to 104°F (5°C to 40°C)
Solvent Capacity: 20 gallons US
Figure 2
This unit is approved for mineral spirits with a flashpoint greater than 140°. Notify manufacturer for latest
list of approved solvents.
CAUTION: Avoid distilling solvents that may include unstable reactives, such as Nitrocellulose.
This unit is ETL listed and conforms to UL 2208, Standard for Solvent Distillation
Units and is certified to CAN/CSA C22.2 no.88.
Specification
Model
501
Model
571
W (Width) Floor Space 32” 39”
D (Depth) Floor Space 27” 29”
OH (Operating Height) 68” 70”
WH (Working Height) 33.50” 33.50”
FS (Front Spacing) 36” 36”
RS (Rear Spacing) 3” 3”
SS (Side Spacing) 4” 4”
Weight (Empty) 326 lbs. 342 lbs.
SPECIFICATIONS
Product Specifications
pproved Solvents
Certifications
