Figure 14. Rear view receiver:
ACCESS DOOR
CONNECTOR
16 CONDUCTOR
CABLE
RESET SWITCH
30
55
SENSITIVITY
SELECT SWITCH
N
A
ALIGNMENT
MODE SWITCH
C0548-00
Figure 15. Rear view transmitter:
ACCESS DOOR
CONNECTOR
6 CONDUCTOR
CABLE
A
N
ALIGNMENT
MODE SWITCH
SW1
L
S
RANGE
SELECT SWITCH
SW2
C0549-00
