System Sensor 6500R User Manual

I56-2081-013 © System Sensor 2009DB200-01-01
6
OPERATION MODES AND TROUBLESHOOTING GUIDE
Pittway Tecnologica S.r.l., Via Caboto 19/3, 34147 TRIESTE, Italy
Percent the
detector has
drifted
<10%
<20%
<30%
<40%
<50%
<60%
<70%
<80%
<90%
<100%
Number of
blinks
output
None
1
2
3
4
5
6
7
8
9
Blinks Output by Yellow
LED and Remote Trouble
Output once the Device
has Passed a Local Test
0832-CPD-0323
EN54-12
Alarm Contacts Fault Contacts Modes Red Yellow Green Dual Digital Display
Readout
Initiating Means
Alarm Remote Fault Remote
Comments and
Troubleshooting Tips
Normal Off Off Blink Off
Successful completion of initialisation or detector reset
Open Off Close Off
Alignment Off On Off On, relative amount of
signal 0-99, or “- -“ if auto gain resetting, or “Lo” if signal too low
Alignment Switch Open Off Open On
Alarm On Off Off Off Smoke, Test Filter, 6500RTS
KEY
Close On Close Off
Fault - Drift Comp Elevated Signal
Off 3 Quick
Blinks
Blink Off Long term drift reference out
of range
Open Off Open On
 Sunlight into detector or
reflector
 Re-align detector
Fault – Drift Comp Reduced Signal
Off 2 Quick
Blinks
Blink Off Long term drift reference out
of range
Open Off Open On
 Clean detector and reflector
Fault Signal – Over Range
Off 2 Quick
Blinks
Blink Off Increase of reflected signal Open Off Open On
 Inspect line of sight between
detector and reflector for reflective objects in path
Fault - Beam Blockage
Off 4 Quick
Blinks
Off Off Beam Blockage Open Off Open On
 Remove Blockage  Faulty Unit
Initialisation – Power On
Off Blink until
complete
Blink Off Apply Power from discharged
state
Open Off Close Off
Initialisation- Alignment Exit
Off Blink until
complete
Blink Off Depressing RESET switch
after alignment
Open Off Close Off
Local Test (6500RS) Pass result
On
Blinks out amount of drift used
Off Off 6500RTS KEY Close On Close Off
Detector remains in alarm until reset
Local Test (6500RS) Fail result
Off
On until reset of timeout
Blink Off 6500RTS KEY Open Off Open On
Detector remains in fault until reset or timeout
Local Test (6500R) Fail Result
Off
As fault mode
Blink Off 6500RTS KEY Open Off Open On
If local test fails will already be in fault
Local Test (6500R) Pass result
On
Blinks out amount of drift used
Off Off 6500RTS KEY Close On Close Off
Detector remains in alarm until reset
