Top Case (Remove or replace)
Removing the Top Case
Before servicing your Thelio, be sure to power off and unplug all cords from the
computer.
Top Case removal is simple and requires, at most, a cross-head (Phillips) screwdriver.
Tools required: Fingers or Cross-head (Phillips) screwdriver
Time estimate: 2 minutes
Difficulty: Easy
Screws: 4 total
- 4 Thumbscrews (Phillips/Crosshead).
Fig. 9: Thelio Outer Case views, front (left), back (middle), Top Case partial removal (right).
Removing the lid will give you easy access to all components inside.
To remove the lid, you’ll need to unscrew the 4 thumbscrews from the back of the Thelio.
These thumbscrews will be on the top left and right, and bottom left and right of the back of the
case.
Do not unscrew any screws in the center of the panel here, as those screws correspond with
parts inside; removing them will not assist you in removing the lid.
System76 Thelio (thelio-b1)
10
