BF 100 S
BF100T
BF 100 TH
Terminal 1. Live supply in
Terminal 2. Neutral supply in
Terminal 2. Switched live supply (Yellow)
Terminal 3. Permanent live supply (Orange)
Terminal 1. Neutral supply (Black)
Remote switch
or Light switch
3 Amp
Double pole fused spur
- Neutral
+ Live
1
MIN
MAX
15
20
30
TIMER
MINUTES
45
40
50
RELATIVE HUMIDITY
60
OFF % ON
90
98
80
70
SWITCHED
LIVE SUPPLY IN
PERMANENT
LIVE SUPPLY IN
NEUTRAL
SUPPLY IN
231
3 AMP
DOUBLE POLE
FUSED SPUR
_
NEUTRAL
+
LIVE
PULLCORD
SWITCH / LIGHT SWITCH
3 AMP
DOUBLE POLE
FUSED SPUR
_
NEUTRAL
+
LIVE
PULLCORD
SWITCH / LIGHT SWITCH
Install this way up!
When mounting on
a wall
Terminal 2. Switched live supply (Yellow)
Terminal 3. Permanent live supply (Orange)
Terminal 1. Neutral supply (Black)
