Description
|
7
Table 9 Dimensions DVC-P/DVC-POC
H
M20x1,5
I
K
F
E
C
D
B
A
[mm]
A B C D E F H K I
190–225 370 320 175
-
335 245 6xM6 213
10 (4x)
315 560 470 330 378 435 330 6xM8 285
10 (4x)
355–400 723 623 390 438 595 450 6xM8 438
12 (4x)
450–500 900 730 465 515 665 535 6xM8 438
12 (4x)
560–630 1150 960 565 585 939 750 8xM8 605
14(4x)
Table 10 Dimensions DVCI-P/DVCI-POC
[mm]
A B C D E F H K I
225 498 438 210
-
335 245 6xM6 213
10(4x)
315 690 583 369 415 435 330 6xM6 285
10(4x)
355–400 877 745 440 439 595 450 6xM8 438
12(4x)
450–500 970 825 479 516 665 535 6xM8 438
12(4x)
560–630 1315 1135 600 619 939 750 8xM8 605
14(4x)
