1. SAVE LIGHT control panel
SAVE LIGHT is an easy to use Control panel for residential air handling units from the SAVE
series. It allows to change between the 4 pre configurated air flow levels. It also indicates if
an alarm is present or if the Filters have to be changed.
It is available in either black or white.
2. Features
The SAVE LIGHT control unit covers the basic functions for operating the ventilation unit;
please find more details in the following sections.
A SAVE TOUCH or SAVE CONNECT module is still required to configure individual settings and
initial commissioning.
2.1 Airflow Levels
The different Airflow levels can be easily controlled via the (+) and (-) buttons:
Press the Button to increase the airflow.
Press the Button to decrease the airflow.
