6
| Introduction
GB
Fig. 1 Type label
Position Description
1
Product code (product specification)
2
Product item number
3
Production order number
4
Serial number
5
Production date (YY.MM.DD)
6
QR code for manufacturing order (MO) number and software version
7
QR code for the spare parts list and documentation
4 Introduction
The SAVE VTC 300 is a heat recovery ventilation unit with a built in counter flow plate heat exchanger. There are two
model options, right (R) and left (L) model (figure 1). The different models are recognized by the control panel which is
situated on the right side of the unit in an (R) unit and on the left side in an (L) unit.
This manual describes basic information how to operate and perform maintenance on the unit and the system it is con-
nected to.
Fig. 1 Right and Left models
Table 1 Symbol description
Symbol Description
A
Supply air
B
Exhaust air
C
Outdoor air
D Extract air
5 Configuration
5.1 General
SAVE VTC 300 has a modern touchscreen LCD control panel, simply known as HMI — Human Machine Interface. The
touchscreen display provides information about current state of the unit and allows you to control all system functions.
211465 | A003
