32
SYSCROLL Air HP 20 25 30 35
Power supply
V/ph/Hz 400 ±( 10%)/3+N/50
Number of refrigerant circuits
1
Total capacity steps
% 0-100
REFRIGERANT
Type
R410A
Charge (1)
kg 5,0 5,6 6,1 7,1
COMPRESSOR
Type
Scroll
Number
1
Start-up type Direct
Oil type
POE
N° of loading stages
0/100
EVAPORATOR
Type Plate
Number
1
Water flow rate
l/s
0,95 1,12 1,29 1,57
Pressure drop
kPa
Refer to Chapt. 8.1
FANS
Type Axial
Number
2
Nominal speed
rpm 900
Air flow rate
m
3
/s 3,1 3,0 3,0 2,9
Power input
kW 0,53 0,54 0,54 0,54
AIR COOLED CONDENSER
Type
Finned tubes
Number
1
Total coil face area per coil
m
2
1,5 1,5 1,5 1,5
PUMPS
Type
Centrifugal
Number
1
Nominal speed
2850
Power input
0,59 0,62 0,64 0,65
HYDRAULIC CONNECTIONS (EVAPORATOR)
Type Threaded gas male
Inlet diameter
inch 1” 1/4
Outlet diameter
inch 1” 1/4
WEIGHT
Shipping weight
kg
Refer to Chapt. 8.5
Operating weight
kg
DIMENSIONS
Length
mm 1477
Width
mm 539
Height
mm 1615
SYSCROLL 20-35 Air HP
8 - Technical Data
(1) Indicative value. Always refer to the value specified on the unit’s label.
