SystemAir SYSCROLL 20-35 Air - 8.5 Dimensional Drawings

35
English
1615
147 1183
147
31
F G
LIFT
30
LIFT
30
457
26
26
508
1441 1818
1477
31
P1
P3
P2P4
352 426
38 172
2501315
255
A
B
D
C
E
N
O
8.5 Dimensional Drawings - SYSCROLL 20-35 CO/HP
8 - Technical Data
Front view Side view
Top view
Dimensions in mm.
NOTES:
A Water inlet Ø1 1/4” FGM
B Water outlet Ø1 1/4” FGM
C Auxiliary lines, electrical connection
D Electrical power supply
E Gauge kit (optional)
F Main switch
G Control display
N Desuperheater inlet ø 1” MGT
O Desuperheater outlet ø 1” MGT
