SYSCROLL Air CO 20 25 30 35
Power supply V/ph/Hz 400(±10%)/3+N/50
Number of refrigerant circuits 1
Total capacity steps % 0-100
REFRIGERANT
Type R410A
Charge (1) kg 4,1 4,6 6,0 6,6
COMPRESSOR
Type Scroll
Number 1
Start-up type Direct
Oil type POE
N° of loading stages 0/100
EVAPORATOR
Type Plate
Number 1
Water flow Rate l/s
0,97 1,14 1,32 1,59
Pressure drop kPa
Refer to Chapt. 8.1
FANS
Type Axial
Number 2 2 2 2
Nominal speed rpm 630 630 630 630
Air flow rate m
3
/s 3,1 3,6 3,6 3,5
Power input kW 0,6 0,6 0,6 0,6
AIR COOLED CONDENSER
Type Finned tubes
Number 1
Total coil face area per coil m
2
1,5 1,5 1,5 1,5
PUMP
Type
Number 1
Nominal speed rpm 2850
Power input kW 0,6 0,62 0,64 0,66
HYDRAULIC CONNECTIONS (EVAPORATOR)
Type Threaded gas male
Inlet Diameter inch 1” 1/4
Outlet Diameter inch 1” 1/4
WEIGHT
Shipping Weight kg
Refer to Chapt. 8.5
Operating Weight kg
DIMENSIONS
Lenght mm 1477
Width mm 539
Height mm 1615
8.2 Physical data
SYSCROLL 20-35 Air CO
8 - Technical Data
(1) Indicative value. Always refer to the value specified on the unit’s label.
