SystemAir SYSHRW Series User Manual

English
23SYSHRW
RCL control recommended
setting
Accessible modes Type
Dip J1 Dip J2
0 1 0
1
Off Cool Heat Auto
Fan
X X X X X ST
X X X X X RC - RH - SH
X X X X X X X RC - RH - SH
Set the DIP switches marked J1 and J2 in accordance with your conguration nd the modes that are accessible.
Dips switches J1 and J2 for
parameterisation
Clip the RCL control onto the support bracket.
Replace the lower screw in such a way that the RCL control is held rmly in place on the support bracket
Lower screw
