SystemAir Topvex FR800 User Manual

Topvex FR800, FR1600, FR3800
Operation and Maintenance Instructions
Systemair Inc.
10
Main menu item Sub-menu item 1 Sub-menu item 2 Explanations
Frost
protection
Active
Cooling
recovery
No
Shows the status of the frost
protection function.
Shows the status of the cooling
recovery function.
External set
point
Not active
Shows the status of the external
set point.
→ Alarm events
Shows all registered alarms
along with the time and date
they occurred.
Move down and up in the list by
pressing↑↓.
→ Input/ Output → Analogue
inputs
Shows the status of the
Analogue inputs.
→ Digital
inputs
Shows the status of the Digital
inputs.
→Universal
inputs
Shows status of Universal
Analogue inputs.
Shows status of Universal
Digital inputs.
→Analogue
outputs
Shows the status of the
Analogue outputs.
→Digital
outputs
Shows the status of the Digital
outputs.
→Temperature Extract air
temp
Act.: °F
Setp: 64.4°F
Shows thecongured
temperature control (Default is
Extract air temp).
Shows the actual temperature
in the chosen control mode.
Shows the temperature for the
chosen control mode.
If cascade
control
Max/min supply
setp.
Max: 86°F
Min: 53.6°F
Shows the maximum and
minimum allowed supply air
temperature in case of cascade
control.
Login to service level needed
to change settings.
Outdoor temp:
°F
Supply air temp
Actual: °F
Setp: 64.4°F
Shows the actual outdoor air
temperature.
Shows the actual supply air
temperature.
Shows the calculated supply
air set point. The exhaust
air controller output signal
generates the supply air
controller’s set point value.
