9
4.3 Menu overview OPERATOR/SERVICE LEVEL
ThemenuoverviewbelowshowsboththeOperatorandServicelevel.Theoverviewofthepartsuniqueto
the Service level in the table below are marked with grey background color. To logon to the Service level
use code 2222 under Access rights.
Main menu item Sub-menu item 1 Sub-menu item 2 Explanations
FR 800 EL
2011-03-15 9:00
System: Stopped
Sp: 18.0 Act: °F
Start screen headline.
Can be set to 5 different layouts.
(Changeableat“systemlevel”
under the conguration menu).
→ Running mode → Running mode Running mode
Auto
Set running mode to Auto, On
or Off.
Running time
SAF: 0.0 h
EAF: 0.0 h
Shows the time in hours that
motor have been operating.
SAF = Supply air fan.
EAF = Exhaust air fan.
→ Selected
function
Control
function
Extract air
control
Fan control
Flow control
Shows type of air temperature
controltheunitisconguredfor.
Shows type of fan speed control
theunitisconguredfor.
Heating: Water
Exchanger:
Rot. Excha
Cooling: Water
Shows type of heating selected.
Shows type of exchanger
selected.
Shows type of cooling selected.
Free cool
active: No
Shows the status of the free
cooling function.
Support control
Active: No
C02/VOC active
Never
Shows the status of the support
control function.
Shows the status of the demand
ventilation(C02/VOC)function.
Fire damper
function
Not active
Operation when
alarm
Stopped
Shows thestatusofthere
damper function.
