Installation |
19
Fasten the damper
8. Insert the damper in the area above the exchanger.
Caution
Do not drag the damper on the exchanger.
9. Lift the damper with the short end on the rail at the outer beams. Observe the small hooks to secure the damper.
10.Fasten the damper by fastening the damper rails with the bolts.
Mount the doors
11.Place the doors in position.
12.Unite the hinges and replace the pin.
214958 | A002
