Technical data |
33
15 Technical data
15.1 Dimensions and weight Topvex SC
Dimensions are given in mm.
Topvex SC20, Topvex SC25
2000
56.3
118 309
765
A
B
CD
E
F
1318
259 415
øG
118
94
H
495814
996
Model
A B C D E F øG H
Topvex SC20 775 375 342 515 126 367 315 552
Topvex SC25 890 432 330 540 132 480 400 667
Topvex SC35
1695
94
877
500
350 413
127
482
668
627 637
240400300
118
2540
118 634 655
705 820
214958 | A002
