SystemAir Topvex SC Installation Instructions

Product information |
1
1 Product information
This manual includes the information required for installing the heat recovery unit type Topvex SC, TC manufactured by
Systemair Sverige AB. The units include the following model options:
The air handling units is delivered with airflow control CAV (Constant Air Volume).
Side connected units:
Topvex SC20, Topvex SC25, Topvex SC35, Topvex SC60, Topvex SC70
Top connected units:
Topvex TC20, Topvex TC25, Topvex TC35, Topvex TC60, Topvex TC70
Options:
The air handling units are delivered with the electrical cabinet and supply air intake on right (R) or left (L) side.
Heater options are electrical (EL), hot water (HW) or none (None).
Defrosting options are bypass defrosting (B) or section defrosting (S).
Fan impeller options are composite or aluminium (M0).
EL heater options:
SC/TC20
4,2 kW 6,5 kW 9,6 kW
SC/TC25 6,5 kW 9,6 kW 11,8 kW
SC/TC35
7,2 kW 11,8 kW 18,1 kW
SC/TC60 9,6 kW 16,2 kW 32,4 kW
SC/TC70
16,2 kW 32,4 kW
HW heater options:
HWH (High power) or HWL (Low power)
Table 1 Example Topvex TC 60 HWH-L
Topvex TC 60 HWH -L
Unit name
Top connected
Size Hot water
heater (High)
Left hand unit
214958 | A002

SystemAir Topvex SC Specifications

General

Brand	SystemAir
Model	Topvex SC
Category	Air Handlers
Language	English
