MFT-PRO
Quick reference guide
EN – 19
Contact voltage (measured during RCD and Ra test)
Range [V] Resolution [V] Accuracy
0 Ut LIM
0.1
-0%, +(5.0rdg + 3V)
Phase sequence test with 1 test lead
Voltage range P-N, P-PE [V] Frequency range
100 265 50Hz/60Hz 5%
Measurement is only carried out by direct contact with live parts (not work by touching the insulation sheath of the cables)
Leakage current (input In1 – STD clamp)
Range [mA] Resolution [mA] Accuracy
2 999
1
(5.0%rdg + 2dgt)
Environmental parameters
Measurement Range Resolution Accuracy
°C
-20.0 60.0°C
0.1°C
(2%rdg + 2dgt)
°F
-4.0 140.0°F
0.1°F
HR%
0.0% 100.0%HR
0.1%HR
DC Voltage
0.1mV 1.0V
0.1mV
Lux
0.001 20.00lux (*) 0.001 0.02Lux
0.1 2.0klux (*) 0.1 2Lux
1 20.0klux (*) 1 20Lux
(*) Accuracy of luxmeter probe is according to Class AA
