39
1 - 2 Adjustable conditioning
The distance of the conditioning plate from the rotor can be adjusted in three positions I, II and III
by means of a single lever A.
Adjustment should be made according to the kind of crop:
Pos. I Pos. II Pos. III
Normal grass crop Grass crop with moderate Juicy and leafy early
content of leaves crops
3
Conditioning rotor
The rotor can be adjusted to two different speeds of revolution by exchanging the V-belt pulley
wheels. Extra V-belt pulley/V-belts for harvest of whole crop are available. The following scheme
is suggested for choice of correct rotor speed.
Type of crop B C
Normal grass crop and crops with
moderate content of leaves
Juicy, leafy early crops and clover
and lucerne/alfalfa
Whole crop (optional equipment
No. 69.990.000)
4
- 5 Swath deflectors
Adjust the swath deflectors D so that the swath is suitable for the forage harvester or baler pick-
up width. The swath should be as even and wide as possible. The swath deflectors are equipped
with adjustable extension pieces E.
Rotor
r.p.m.
600 D = 200 D = 230
900 D = 230 D = 200
450 D = 150 D = 230
