Taarup 4032C - Technical data; Fitting to the tractor

7
XXXX
}
Technical data (Conversion table for SI-units, - see page 77).
Model 4024 Model 4028 + C Model 4032 + C Model 4036 + C
Weight with swivel hitch .............................................. kg 1380 1480 1650 1760
**)
1530 **) 1700 **) 1810
Weight with wide angle shaft ....................................... kg 1320 1420 1580 1680
P.T.O. (power take off - number of revolutions):
Machines with swivel hitch ............................. r.p.m. 540/1000 540/1000 540/1000 540/1000
Machines with wide angle shaft....................... r.p.m. 540 540 540 540/1000
Hydraulic connection: 1 set double-acting ..................
+ 1 pc. single-acting................
Power requirement........................................................ kW (HP) 45 (60) 50 (70) 60 (80) 70 (90)
Number of discs............................................................ pcs. 6 7 8 9
Number of knives replaceable ...................................... pcs. 12 14 16 18
Stubble height (continously variable adjustable) ......... mm 30 - 40 30 - 40 30 - 40 30 - 40
high cut skids (optional equipment) ................ mm max. 80 max. 80 max. 80 max. 80
Speed conditioner, ........................................................ r.p.m. 600 or 900 600 or 900 600 or 900 600 or 900
Speed of discs ............................................................... min-
1
3000 3000 3000 3000
Tyre sizes ...................................................................... 10.00 - 12 10.00 - 15 10.00 - 15 10.00 - 15
or 10.00 - 15 or 15.00 - 17 or 15.00 - 17 or 15.00 - 17
Working speed (depending on crop) ............................ kph 6 - 15 6 - 15 6 - 15 6 - 15
Cutting width ................................................................ mm approx. 2400 2800 3200 3600
Transport width............................................................. mm approx. 2400 2850 3150 3550
Model 4028 C - model 4032 C - model 4036 C cannot be fitted with a wide-angle hitch.
The weight applies to the models 4028 C - 4032 C & 4036 C.
We reserve the right to make alterations without notice. We also make reservations as to possible misprints in this manual.
Fitting to the tractor
The tractor must be of a suitable size, adhere to the local laws. The minimum kW/HP are shown
above. When operating on hilly ground or operating with heavy crops a bigger tractor is recommend-
ed.
Machines with swivel hitch: Couple the drawbar to the lift arms of the tractor. The lift arms must be equipped with
stabilizing chains.
Machines with wide angle shaft: Couple the drawbar to the drawbar of the tractor. The drawbar must be fitted
with a clevis and should be longitudinally adjustable, - see page 33 top.
Dimensions drawing, page 6:
Models 4024 - 4028 - 4032 - 4036: The position of the towing eye for machines with wide-angle hitch is shown by
A and B. The position of the towing eye for machines with swivel hitch is shown by C and D.
Models 4028 C - 4032 C - 4036 C: The position of the towing eye is shown by E, F and G.
*)
