User Manual 9250
3-6 Portrayal
Test Results
Pass Fail
14. Repeat the test procedure as above for the auxiliary inputs
Test Results
Pass Fail
Square wave
Characteristics
Equipment: Oscilloscope, Function generator
Preparation:
15. Configure the Oscilloscope as follows:
16. Termination: 50Ω feed through at the oscilloscope input
17. Setup: As required for the test
18. Connect 9250 Channel 1/2 output to the oscilloscope input
19. Configure the Function Generator as follows:
20. Function: Square wave
21. Frequency: 1MHz
22. Amplitude: 2Vp-p
23. Connect the function generator to the 9250 channel 1/2 input
Test Procedure
1. Perform Square wave Characteristics tests on both channels
using Table 3-2
Table 3- 32 , Square wave Characteristics Tests
Oscilloscope Reading
9250 Setting Error Limits CH 1 Output CH 2 Output Pass Fail
Rise/Fall Time
≤ 22 ns
Ringing < 7% + 10 mV
Over/undershoot < 7% + 10 mV
2. Repeat the test procedure as above for the auxiliary inputs
Test Results
Pass Fail
