User Manual 9250
3-12 Portrayal
Channel 1, Auxiliary
Offset Adjustment
Equipment: Oscilloscope, waveform generator, x10 attenuator
Procedure:
64. Configure the waveform generator as follows:
65. Frequency: 1MHz
66. Function Ch1: Square wave
67. Function Ch2: DC
68. Amplitude Ch1: 200mVp-p (may vary depending on
the configured gain)
69. Amplitude Ch2: 8V (may vary depending on the
configured gain)
70. Connect the waveform generator channel 1 output to the
9250, channel 1 input
71. Connect the waveform generator channel 2 output to the
9250, rear panel Channel 1 DC Offset auxiliary input
72. Connect the 9250 channel 1 through the x10 attenuator to the
oscilloscope
73. Set oscilloscope to dc coupling and 50Ω termination
Adjustment:
1. Adjust RV7 for dc offset of 8V ±1/2 small division
Channel 2, Auxiliary
Offset Adjustment
Equipment: Oscilloscope, waveform generator, x10 attenuator
Procedure:
74. Configure the waveform generator as follows:
75. Frequency: 1MHz
76. Function Ch1: Square wave
77. Function Ch2: DC
78. Amplitude Ch1: 200mVp-p (may vary depending on
the configured gain)
79. Amplitude Ch2: 8V (may vary depending on the
configured gain)
80. Connect the waveform generator channel 1 output to the
9250, channel 2 input
81. Connect the waveform generator channel 2 output to the
9250, rear panel Channel 2 DC Offset auxiliary input
82. Connect the 9250 channel 2 through the x10 attenuator to the
oscilloscope
83. Set oscilloscope to dc coupling and 50Ω termination
Adjustment:
1. Adjust RV4 for dc offset of 8V ±1/2 small division
