What to do if there is oil leakage in Tadano TR-150XL-4?
If you notice oil leakage in your Tadano Construction Equipment, the issue might stem from insufficient plug tightening torque or a damaged O-ring. Try retightening the plug to the specified torque. If the leakage persists, the O-ring is likely damaged and needs replacement.
Why is the steering hard on my Tadano TR-150XL-4?
Hard steering in your Tadano Construction Equipment can be caused by several factors. Dust caught in the relief valve, a spool stuck due to dust, or clogged orifices in the plug and spool could be the culprits. To resolve this, disassemble, clean, and reassemble the affected components. If the spool remains stuck, consider replacing it.
How to troubleshoot abnormal sound in Tadano Construction Equipment?
An abnormal sound in your Tadano Construction Equipment could be due to dust caught in the relief valve or a spool stuck (by dust). Disassemble, clean, and reassemble the components. If the issue persists with the spool, consider replacing it.
What to do if Tadano Construction Equipment has hard steering with engine at low idle?
If your Tadano Construction Equipment experiences hard steering when the engine is at low idle, it could be due to an insufficient pump delivery rate, control pressure that is too low, or excessive CF piping resistance. Check the pump, readjust the control pressure, or replace the piping to resolve this.
Definitions of safety alert symbols and terms used in the manual.
General safety guidelines for servicemen before performing maintenance.
Specific safety advice for various working procedures.
Precautions for safely removing and taking apart machine components.
Guidelines for safely putting machine components back together.
Safety advice for operating the machine and its systems.
Rules for disposing of waste materials like oils and filters.
Information on applicable specification numbers for the service manual.
List of related service manuals for comprehensive repair.
Overview of the crane's technical specifications for different models.
Table for converting length measurements between metric and imperial units.
Table for converting area measurements between metric and imperial units.
Table for converting volume measurements between metric and imperial units.
Table for converting mass measurements between metric and imperial units.
Table for converting pressure measurements between different units.
Conversion factors for torque and moment measurements.
Table for converting temperatures between Celsius and Fahrenheit.
Table for converting force measurements between different units.
General information about the hydraulic power generating system.
Information on the double variable displacement hydraulic pump.
General information about the outrigger system.
Details on the structure and function of the jack cylinder.
General information about the swing system.
Details on the structure and components of the swing assembly.
General information about the boom elevating system.
Details on the structure and function of the elevating cylinder.
General information for the 2M2D winch system.
Details on the structure and reassembly of the winch.
General information about the telescoping system.
Details on the structure and disassembly of the six-section boom.
General overview of the safety system components and functions.
Details on the structure, function, and adjustment of the boom length/angle detector.
Procedure for replacing crane cab glass components.
Information on the air conditioning system, its components, and operation.
Overview of the hydraulic pilot control system.
Overview of the pneumatic control devices used in the system.
General information about the steering system.
Details on the priority valve's structure, operation, and troubleshooting.
General overview of the brake system.
Details on the structure, function, and maintenance of the service brake.
General information about the suspension system.
Details on the structure of the front spring lock cylinder.
Table of hydraulic pressure settings and check procedures for various systems.
Table of air pressure settings and specifications for various components.
Step-by-step instructions for bleeding air from hydraulic and pneumatic systems.
Diagram illustrating the complete hydraulic system.
Diagram of the torque converter hydraulic circuit.
Diagram of the pneumatic brake circuit.
Diagram of the electric circuits related to the AML and crane functions.
Definitions of safety alert symbols and terms used in the manual.
General safety guidelines for servicemen before performing maintenance.
Specific safety advice for various working procedures.
Precautions for safely removing and taking apart machine components.
Guidelines for safely putting machine components back together.
Safety advice for operating the machine and its systems.
Rules for disposing of waste materials like oils and filters.
Information on applicable specification numbers for the service manual.
List of related service manuals for comprehensive repair.
Overview of the crane's technical specifications for different models.
Table for converting length measurements between metric and imperial units.
Table for converting area measurements between metric and imperial units.
Table for converting volume measurements between metric and imperial units.
Table for converting mass measurements between metric and imperial units.
Table for converting pressure measurements between different units.
Conversion factors for torque and moment measurements.
Table for converting temperatures between Celsius and Fahrenheit.
Table for converting force measurements between different units.
General information about the hydraulic power generating system.
Information on the double variable displacement hydraulic pump.
General information about the outrigger system.
Details on the structure and function of the jack cylinder.
General information about the swing system.
Details on the structure and components of the swing assembly.
General information about the boom elevating system.
Details on the structure and function of the elevating cylinder.
General information for the 2M2D winch system.
Details on the structure and reassembly of the winch.
General information about the telescoping system.
Details on the structure and disassembly of the six-section boom.
General overview of the safety system components and functions.
Details on the structure, function, and adjustment of the boom length/angle detector.
Procedure for replacing crane cab glass components.
Information on the air conditioning system, its components, and operation.
Overview of the hydraulic pilot control system.
Overview of the pneumatic control devices used in the system.
General information about the steering system.
Details on the priority valve's structure, operation, and troubleshooting.
General overview of the brake system.
Details on the structure, function, and maintenance of the service brake.
General information about the suspension system.
Details on the structure of the front spring lock cylinder.
Table of hydraulic pressure settings and check procedures for various systems.
Table of air pressure settings and specifications for various components.
Step-by-step instructions for bleeding air from hydraulic and pneumatic systems.
Diagram illustrating the complete hydraulic system.
Diagram of the torque converter hydraulic circuit.
Diagram of the pneumatic brake circuit.
Diagram of the electric circuits related to the AML and crane functions.
General| Model | TR-150XL-4 |
|---|---|
| Maximum Lifting Capacity | 15 tons |
| Boom Type | Telescopic |
| Number of Boom Sections | 4 |
| Number of Axles | 2 |
| Drive | 4x2 |
| Maximum Boom Length | 24.4 meters |
| Maximum Reach | 22.4 meters |
