T2008 Parts List (IPN 220-01170-03)
Ref VAR IPN Description Ref VAR IPN Description
M2000-00
8.1.17
Copyright TEL 31/12/97
8.1.10 PCB Information
CBR 017-15470-01 CAP CER SURFACE BARRIER 47N 20% 50
C1 020-19220-03 CAP ELECT RADL 2200M 35V 16X31MM
C2 020-19220-03 CAP ELECT RADL 2200M 35V 16X31MM
C3 020-19220-03 CAP ELECT RADL 2200M 35V 16X31MM
C4 020-19220-03 CAP ELECT RADL 2200M 35V 16X31MM
C5 020-19220-03 CAP ELECT RADL 2200M 35V 16X31MM
C6 020-19220-03 CAP ELECT RADL 2200M 35V 16X31MM
C7 020-09470-02 CAP ELECT RADL 470M 16V 10X20MM
C8 017-15470-01 CAP CER SURFACE BARRIER 47N 20% 50
C9 051-00006-06 WIRE LINK T/C
C10 022-05150-01 CAP MYLAR 15N 10% 50V
C11 022-04220-01 CAP MYLAR 2N2 10% 50V
C14 022-05100-01 CAP MYLAR 10N 10% 50V
D1 001-00011-50 (S) DIODE MUR810 8A 100V FAST RECOV
D2 001-00012-91 (S) DIODE 16V TRANSIENT SUPPRESSOR
F1 21 265-00010-45 FUSE 1A CARTRIDGE 6*32MM SLOBLOW
F1 22 265-00010-05 FUSE 3A CARTRIDGE 6*32MM BS4265
F1 23 265-00010-45 FUSE 1A CARTRIDGE 6*32MM SLOBLOW
F1 24 265-00010-45 FUSE 1A CARTRIDGE 6*32MM SLOBLOW
F2 265-00010-07 FUSE 10A CARTRIDGE 6*32MM BS4265
IC1 002-00016-63 (S) IC TL494/594 SMPS PWM CTRL
LED1 008-00012-52 (S) LED 2MM TOWER 5MM BASE RED
L1 056-00010-47 IND FXD 125UH PWR CHOKE TOROIDAL
L2 056-00010-20 IND FXD 25UH PWR CHOKE
PL1 240-00020-68 HEADER 2WAY PCB MTG STD
Q1 000-00022-07 (S) XSTR 2N3772 NPN PWR TO-204
Q2 000-00012-15 (S) XSTR BD234 PNP AF PWR TO126
Q3 000-00011-10 (S) XSTR BC548B/BC547B NPN AF SML SI
Q4 000-00011-10 (S) XSTR BC548B/BC547B NPN AF SML SI
R1 030-53120-20 RES FILM AI 120E 5% 0.4W 4X1.6MM
RV1 042-03470-01 RES PRESET 470E CARBON 10MM FLAT
RB1 001-00011-37 (S) DIODE BRIDGE RECT 50V/25AMP
RV2 042-03470-01 RES PRESET 470E CARBON 10MM FLAT
R2 033-03330-00 RES MP816 PWR FILM 330E 10% 16W TO-2
R3 030-52330-20 RES FILM AI 33E 5% 0.4W 4X1.6MM
R4 030-54680-20 RES FILM AI 6K8 5% 0.4W 4X1.6MM
R5 030-54390-20 RES FILM AI 3K9 5% 0.4W 4X1.6MM
R6 030-54180-20 RES FILM AI 1K8 5% 0.4W 4X1.6MM
R7 030-55100-20 RES FILM AI 10K 5% 0.4W 4X1.6MM
R8 030-54470-20 RES FILM AI 4K7 5% 0.4W 4X1.6MM
R9 030-53120-20 RES FILM AI 120E 5% 0.4W 4X1.6MM
R10 030-55680-20 RES FILM AI 68K 5% 0.4W 4X1.6MM
R11 030-55100-20 RES FILM AI 10K 5% 0.4W 4X1.6MM
R12 030-54330-20 RES FILM AI 3K3 5% 0.4W 4X1.6MM
R13 030-54390-20 RES FILM AI 3K9 5% 0.4W 4X1.6MM
R14 030-55220-20 RES FILM AI 22K 5% 0.4W 4X1.6MM
R15 030-54330-20 RES FILM AI 3K3 5% 0.4W 4X1.6MM
R16 030-53470-20 RES FILM AI 470E 5% 0.4W 4X1.6MM
R17 030-53470-20 RES FILM AI 470E 5% 0.4W 4X1.6MM
R18 039-10018-63 RES WIRE WOUND 0.017E A4M1863 T508
R20 030-56220-20 RES FILM AI 220K 5% 0.4W 4X1.6MM
R21 030-53100-20 RES FILM AI 100E 5% 0.4W 4X1.6MM
SW1 232-00010-21 SWITCH PUSH SPST MAINS ON/OFF
*T1 21 053-00010-53 XFMR T4063A 230V MAINS PROTECTED
*T1 22 053-00010-51 XFMR T4065 115V MAINS T508
*T1 23 053-00010-53 XFMR T4063A 230V MAINS PROTECTED
*T1 24 053-00010-53 XFMR T4063A 230V MAINS PROTECTED
