M2000-00

T2020, T203X, T2040, T2050 & T2060 HC11 Logic PCB

7.11.13

Ref Var IPN Description Ref Var IPN Description

IPN 220-01344-04

#012 2050 038-13680-00 RES 0603 CHIP 680E 1/16W +-5%

#015 2020 038-14470-00 RES 0603 CHIP 4K7 1/16W +-5%

#017 2060 038-15100-00 RES 0603 CHIP 10K 1/16W +-5%

#018 203X 038-15270-00 RES 0603 CHIP 27K 1/16W +-5%

#019 2040 038-15470-00 RES 0603 CHIP 47K 1/16W +-5%

C501 015-23680-08 CAP CER 0805 CHIP 680P 10% X7R 50V

C502 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C503 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C504 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C505 018-12390-10 CAP 0603 CHIP 39P 50V NPO +-1%

C506 018-12220-10 CAP 0603 CHIP 22P 50V NPO +-1%

C507 018-12270-10 CAP 0603 CHIP 27P 50V NPO +-1%

C508 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C509 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%

C510 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C511 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C512 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%

C514 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C514A 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%

C514B 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%

C516 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C517 015-23680-08 CAP CER 0805 CHIP 680P 10% X7R 50V

C519 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C520 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C522 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C523 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C524 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V

C525 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C526 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C527 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C529 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C530 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C532 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%

C533 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C534 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C535 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C536 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26

C537 016-07470-01 CAP ELECT 6X4MM CHIP 4M7 20% 16V

C538 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C540 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C541 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C550 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C560 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C570 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C571 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C600 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%

C601 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26

C602 018-12820-10 CAP 0603 CHIP 82P 50V NPO +-1%

C603 015-23220-01 CAP CER 0805 CHIP 220P 5% NPO 50V

C605 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26

C607 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C608 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C609 018-12470-10 CAP 0603 CHIP 47P 50V NPO +-1%

C610 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26

C611 018-13100-10 CAP 0603 CHIP 100P 50V NPO +-1%

C613 015-24470-08 CAP CER 0805 CHIP 4N7 10% X7R 50V

C614 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V

C615 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V

C616 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V

C617 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C618 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C619 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C620 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C621 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C622 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C623 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C624 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C625 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C626 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26

C627 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C628 018-15100-00 CAP 0603 CHIP 10N 50V X7R +-10%

C629 015-23220-01 CAP CER 0805 CHIP 220P 5% NPO 50V

C630 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V

#C631 2020 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

#C631 2040 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

#C631 2050 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C635 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V

C635A 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V

C636 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C637 018-11470-10 CAP 0603 CHIP 4P7 50V NPO +-0.1P

C638 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C639 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V

C640 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V

C641 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%

C642 015-23220-01 CAP CER 0805 CHIP 220P 5% NPO 50V

C643 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V

C644 015-25150-08 CAP CER 0805 CHIP 15N 10% X7R 50V

C645 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C646 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26

C647 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C648 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V

C650 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C651 018-13150-00 CAP 0603 CHIP 150P 50V NPO +-5%

C652 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%

C653 018-14100-00 CAP 0603 CHIP 1N 50V X7R +-10%

#C661 2020 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C661 203X 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C661 2040 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C661 2050 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C661 2060 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C662 2020 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C662 203X 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C662 2040 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C662 2050 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C662 2060 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C663 2020 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C663 203X 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C663 2040 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C663 2050 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C663 2060 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C664 2020 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C664 2040 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C664 2050 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C664 2060 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C665 2020 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C665 2040 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C665 2050 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C665 2060 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C666 2020 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C666 2040 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C666 2050 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C666 2060 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C667 2020 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C667 2040 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C667 2050 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

#C667 2060 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

C700 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-10% 26

C701 016-08470-01 CAP ELECT SMD 6X4MM 47M 16V

#C704 2020 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-1

#C704 203X 014-07470-00 CAP TANT CHIP 4U7 'B' CASE 16V +-1

#C704 2040 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-1

#C704 2050 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-1

#C704 2060 014-07470-01 CAP TANT CHIP 4U7 'B' CASE 25V +-1

C705 015-24470-08 CAP CER 0805 CHIP 4N7 10% X7R 50V

#C706 203X 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

#C706 2060 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V

C720 018-16100-01 CAP 0603 CHIP 100N +80-20% Y5V 16V

7.11 T2020, T203X, T2040, T2050 & T2060 HC11 Logic PCB

T2000 HC11 Logic Parts List (IPN 220-01344-04)

Parts List Amendments
