TN-906-AN Page 7 of 20
© Tait Electronics Limited 21 December 2005
Figure 4 Direct connection to base stations with or without a TaitNet RS-232 system interface
board
Cables 1, 2 & 3 9-way straight through (not null modem) RS-232 cable
Cable 4 9-way null modem RS-232 cable
Cable 5 APS power cable, either AC mains or –48VDC, depending on the model chosen
Notes
■ The illustration above shows base stations with TaitNet RS-232 system interface
boards, but front or rear connection can be used.
APS
APS Power
Cable 1
Cable 2
Cable 4
Cable 5
Cable 3
Service Kit
Single channel
Dual channel
To Next Page
