Troubleshooting 127
RSSI Displays the received signal strength (RSSI) of the
current channel.
Rx 1011 Receives a 1011 Hz Hz tone and displays the
received signal strength (RSSI) and the bit error rate
(BER) of the received signal. Also displays the
channel status (CNV, TCH, CCH
1
) and the mode
(PH1
2
).
Site display Shows the channel number, signal strength and
system-identity code (SYSCODE) for the currently
registered trunked site.
Site measure Lists the current trunked site (indicated with an
asterisk) and up to six detected adjacent sites, with
received signal strength (RSSI) information.
Tone test Generates an audible tone for the duration of the
test.
Tx 1011 Transmits a tone of 1011 Hz Hz on the current P25
channel.
Tx 1011 Cal Transmits a 1011 Hz Hz tone on the current channel
with a bit error rate (BER) of 5%.
Tx power test Displays hardware-related information while the
radio is transmitting. Information includes the final
PA current (in mA), and estimated forward and
reverse power levels (in W) along with an indication
of (OK) or (!)
1. CNV = conventional, TCH = traffic channel, CCH = control channel
2. ANA = analog, PH1 = P25 Phase 1
Test Description
