21 Calibration basics Tuneup
August 2004 © Tait Electronics Ltd
2.4 Viewing calibration test results
After you have finished one or more calibration tests, you can preview the
results of those tests. This can be useful before programming the radio to
send the new calibration data to the radio.
To view calibration data, navigate to the Raw Data form and click on the
various tab pages. See “Raw data reference” on page 30 for more on the
information available.
2.5 Viewing calibration files
Before and after calibrating a radio, it is recommended that you save the
radio’s calibration database to file (see “Calibrating the radio” on page 18).
To open and view a file saved to disk
1. Select the File > Open menu command, or click the Open button
on the toolbar.
2. Navigate to the folder where the file is located.
3. Select the desired file to open.
4. Click the Open button.
5. View the data. You can either view a print output of the file’s data, or
view the data on-screen.
Print output:
a. Select the File > Print menu command, or click the Print button
on the toolbar.
b. Click the Select All button.
c. Click Print.
Screen output:
a. Connect a radio to the PC.
The radio does not have to match the file saved to disk - it can be any
radio that the Calibration Application recognises.
b. View the data on the Specifications, Deviation/Squelch, and Raw
Data forms.
Note The data on these forms will belong to the file opened, not the
attached radio.
