Midian Encryption Programming and Service Manual Tait Orca Portable (TOP) Encryption 39
June 2006 © Tait Electronics Limited
Fit Flex to TOP PCB (top side)
1. Turn PCB over and bend flex carefully around PCB as shown
2. Bend flex at crease, then holding flex in place with tweezers, solder
flex pads to the pads vacated by C567
3. Solder flex to can, holding soldering iron to each point for at least
three seconds to ensure permanent join
4. Solder single flex pad indicated to IC512 pin 1
5. Solder flex pad to pad vacated by R4, as indicated
6. Solder single flex pad indicated to TP13
Note Take care not to short adjacent components when soldering to
TP13
1
6
4
2
3
5
