40 Tait Orca Portable (TOP) Encryption Midian Encryption Programming and Service Manual
June 2006 © Tait Electronics Limited
Fit TOP PCB back into chassis
1. Slide PCB back into chassis, carefully aligning the chassis Auxiliary
Connector Flex into the PCB top side.
2. Replace the screw through the can where shown
3. Replace the washers, nuts and knob seal on the radio top
4. Fix the foam cushioning pad onto the flexiloom where shown, using
double-sided tape
3
1
2
4
